A hard-working thermal drone

The DJI Matrice 30T is a workhorse of an enterprise drone, with a flexible tri-camera system that includes a detailed thermal view and suite of advanced features. This makes it a perfect fit for jobs as wide ranging as industrial inspection and search and rescue.

You can manually control the drone either solo or with a partner, with one person controlling the drone and the other the camera. You can also plan out a flight path with several waypoints in advance. These paths can be saved and repeated to get started faster on subsequent runs.

Whether you're running a programmed light path or actively taking control, the M30T's advanced six-way obstacle detection helps protect your investment, so and means operators can fly with confidence while performing complex or otherwise dangerous jobs.

Tri-camera design

The M30T allows you to switch between three different cameras on the fly: two 4K visual cameras and a powerful thermal camera. The 12-megapixel wide and 48-megapixel zoom visual cameras are great for surveys and mapping, while the 640x512 resolution thermal camera accurately measures temperature, making it ideal for emergency response applications like firefighting. You can switch between each camera on the fly, letting you choose the best view in real-time as your needs change during an operation.

Both visual cameras record smooth 4K video, and each is equipped with a 1/2" CMOS sensor for excellent image quality. A built-in laser rangefinder also lets you pinpoint the exact position of targets in your view. This level of clarity and detail helps ensure you're capturing all the information you need for the job at hand. The zoom camera is also capable of up to 200X hybrid zoom, so your team can scout subjects ahead and keep the drone at a safe distance.

Intuitive controls and software

The included RC Plus remote controller comes with DJI Pilot 2 built-in, DJI's updated and improved flight controls. Flight and navigation details are displayed clearly on the controller's bright, 7-inch touchscreen. The M30T also includes three months of DJI FlightHub 2. This project management software allows for simultaneous collaboration between multiple teams working on the same project with live mission streaming. Users can even add live annotations for the drone operator to respond to for efficient coordination.

Rugged and powerful

The M30T is made to work in a wide variety of environments. It can operate in extreme cold and heat, from -4° to 122°F, and its built-in FPV camera is optimized for low-light conditions. Smart Low-Light Photo mode makes sure you can capture detailed images, even during nighttime missions. This drone can also resist winds up to 33.4 miles per hour, and it's IP55-certified against dust and rain.

Once it's in the sky, the drone flies fast, up to an impressive 51.3 miles per hour, and stays airborne for up to 41 minutes at a time (both batteries equipped). The flight batteries are hot-swappable and a charging station is included, you can get the drone back up in the air with minimal interruption.

Strong transmission, stable controls

Getting a fuzzy feed or losing the video connection entirely mid-flight is disruptive and potentially disastrous at high speeds. Luckily, the DJI M30T uses OcuSync 3 Enterprise, DJI's impressive transmission system. This wireless technology automatically switches between two different bands (2.4 GHz and 5.8 GHz) to resist pesky interference and provide reliable high-definition video transmission.

OcuSync's low-latency transmission keeps your controls sharp and responsive. With a range up to 9.3 miles, you also have some serious flexibility. Your team can survey a forested mountainside, craggy ravine, or crowded city block — all while planted safely on terra firma.

Third-party support

With an open-source SDK (software developer kit) you can develop custom apps and benefit from the work put together by the wider drone community.

This means you can create or take advantage of third-party tools and services, helping you expand and refine your drone's capabilities. Support includes the hardware of the drone itself, but also payloads and third-party docks.

Top-notch security

You can opt to store your data locally on the drone or an SD card. Both encrypt your data with password protection, and that password isn't stored anywhere on DJI's end. This means if the drone crashes or is lost, no one will be able to retrieve the data without your password. If need be, you can also erase all of your data on the drone with a single tap in the DJI Pilot 2 interface.

DJI also protects live video transmission with AES encryption. You can opt in to store data on DJI's cloud, too, which uses multilayered systems including DDos, WAF, Gateway, and RASP protection. Sensitive information like personal or location details receive additional AES-256-CBC encryption.

Peace of mind

Accidents happen to the best of us. With Enterprise Care Plus covering damage from collisions, water, drops, signal interference, and even user error, you can rest a little easier. This plan includes unlimited product replacements within one year. Enterprise Care Plus is auto-activated when you register the M30T.

Aircraft

• Dimensions
  (unfolded, excl. propellers)

• 470×585×215 mm (L×W×H)

• Dimensions (folded)

• 365×215×195 mm (L×W×H)

• Diagonal Wheelbase

• 668 mm

• Weight (incl. two batteries)

• 3770 ± 10 g

• Max Takeoff Weight

• 3998 g

• Operation Frequency^[1]

• 2.4000-2.4835 GHz; 5.725-5.850 GHz

• Transmitter Power (EIRP)

• 2.4 GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC)
  5.8 GHz: <33 dBm (FCC/SRRC); <14 dBm (CE)

• Hovering Accuracy
  (windless or breezy)

• Vertical: ±0.1 m (Vision System enabled); ±0.5 m (N-mode with GPS); ±0.1 m (RTK)
  Horizontal: ±0.3 m (Vision System enabled); ±1.5 m (N-mode with GPS); ±0.1 m (RTK)

• RTK Positioning Accuracy
  (fixed RTK enabled)

• 1 cm+1 ppm (horizontal)
  1.5 cm+1 ppm (vertical)

• Max Angular Velocity

• Pitch: 150°/sec.; Yaw: 100°/sec.

• Max Tilt Angle

• 35° (N-mode and Forward Vision System enabled: 25°)

• Max Ascent/Descent Speed

• 6 m/s, 5 m/s

• Max Tilt Descent Speed

• 7 m/s

• Max Horizontal Speed

• 23 m/s

• Max Service Ceiling Above Sea Level (without other payload)

• 5,000 m (with 1671 propellers)
  7,000 m (with 1676 propellers)

• Max Wind Resistance

• 15 m/s
  12 m/s during taking off and landing

• Max Hover Time ^[2]

• 36 min

• Max Flight Time^[2]

• 41 min

• Motor Model

• 3511

• Propeller Model

• 1671
  1676 High Altitude (not included)

• Ingress Protection Rating^[3]

• IP55

• GNSS

• GPS+Galileo+BeiDou+GLONASS
  (GLONASS is supported only when RTK module is enabled)

• Operating Temperature

• -20° to 50° C (-4° to 122° F)

Gimbal

• Angular Vibration Range

• ±0.01°

• Controllable Range

• Pan: ±90°
  Tilt: -120° to +45°

• Mechanical Range

• Pan: ±105°
  Tilt: -135° to +60°
  Roll: ±45°

Zoom Camera

• Sensor

• 1/2" CMOS, Effective pixels: 48M

• Lens

• Focal length: 21-75 mm (equivalent: 113-405 mm)
  Aperture: f/2.8-f/4.2
  Focus: 5 m to ∞

• Exposure Compensation

• ±3 ev (using 1/3 ev as step length)

• Electronic Shutter Speed

• Auto Mode:
  Photo: 1/8000-1/2 s
  Video: 1/8000-1/30 s
  M Mode:
  Photo: 1/8000-8 s
  Video: 1/8000 -1/30 s

• ISO Range

• 100-25600

• Max. Video Resolution

• 3840×2160

• Max Photo Size

• 8000×6000

Wide Camera

• Sensor

• 1/2" CMOS, Effective pixels: 12M

• Lens

• DFOV: 84°
  Focal length: 4.5 mm (equivalent: 24 mm)
  Aperture: f/2.8
  Focus: 1 m to ∞

• Exposure Compensation

• ±3 ev (using 1/3 ev as step length)

• Electronic Shutter Speed

• Auto Mode:
  Photo: 1/8000-1/2 s
  Video: 1/8000-1/30 s

  M Mode:
  Photo: 1/8000-8 s
  Video: 1/8000-1/30 s

• ISO Range

• 100-25600

• Max. Video Resolution

• 3840×2160

• Photo Size

• 4000×3000

Thermal Camera

• Thermal Imager

• Uncooled VOx Microbolometer

• Lens

• DFOV: 61°
  Focal length: 9.1 mm (equivalent: 40 mm)
  Aperture: f/1.0
  Focus: 5 m to ∞

• Infrared Temperature Measurement Accuracy^[4]

• ±2°C or ±2% (using the larger value)

• Video Resolution

• Infrared Image Super-resolution Mode: 1280×1024
  Normal Mode: 640×512

• Photo Size

• Infrared Image Super-resolution Mode: 1280×1024
  Normal Mode: 640×512

• Pixel Pitch

• 12 um

• Temperature Measurement Method

• Spot Meter, Area Measurement

• Temperature Measurement Range

• High Gain Mode: -20° to 150° C (-4° to 302° F)
  Low Gain Mode: 0° to 500° C (32° to 932° F)

• Temperature Alert

• Supported

• Palette

• White Hot/Black Hot/Tint/Iron Red/Hot
  Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2

FPV Camera

• Resolution

• 1920×1080

• DFOV

• 161°

• Frame Rate

• 30 fps

Laser Module

• Wavelength

• 905 nm

• Max Laser Power

• 3.5 mW

• Single Pulse Width

• 6 ns

• Measurement Accuracy

• ± (0.2 m + D×0.15%)
  D is the distance to a vertical surface

• Measuring Range

• 3-1,200 m (0.5×12 m vertical surface with 20% reflectivity)

Vision Systems

• Obstacle Sensing Range

• Forward: 0.6-38 m
  Upward/Downward/Backward/Sideward: 0.5-33 m

• FOV

• 65° (H), 50° (V)

• Operating Environment

• Surfaces with clear patterns and adequate lighting (> 15 lux)

Infrared Sensing Systems

• Obstacle Sensing Range

• 0.1 to 10 m

• FOV

• 30°

• Operating Environment

• Large, diffuse, and reflective obstacles (reflectivity >10%)

TB30 Intelligent Flight Battery

• Capacity

• 5880 mAh

• Voltage

• 26.1 V

• Battery Type

• Li-ion 6S

• Energy

• 131.6 Wh

• Net Weight

• Approx. 685 g

• Operating Temperature

• -20° to 50° C (-4° to 122° F)

• Storage Temperature

• 20° to 30° C (68° to 86° F)

• Charging Temperature

• -20° to 40° C (-4° to 104° F)
  (When the temperature is lower than 10° C (50° F), the self-heating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery)

• Chemical System

• LiNiMnCoO2

Auxiliary Lights

• Effective Illumination Distance

• 5 m

• Illumination Type

• 60 Hz, solid glow

Remote Controller

• Screen

• 7.02 inch LCD touchscreen, with a resolution of 1920×1200 pixels, and high brightness of 1200 cd/m²

• Internal Battery

• Type: Li-ion (6500 mAh @ 7.2 V)
  Charge Type: Supports battery station or USB-C charger maximum rated power 65W (max voltage of 20V)
  Charge Time: 2 hours
  Chemical System: LiNiCoAIO2

• External Battery(WB37 Intelligent Battery)

• Capacity: 4920 mAh
  Voltage: 7.6 V
  Battery Type: Li-ion
  Energy: 37.39 Wh
  Chemical System: LiCoO2

• Operating Time^[5]

• Internal Battery: Approx. 3 hours 18 min
  Internal Battery + External Battery: Approx. 6 hours

• Ingress Protection Rating^[3]

• IP54

• GNSS

• GPS+Galileo+BeiDou

• Operating Temperature

• -20° to 50° C (-4° to 122° F)
